RSLB10M Magnetic Laser Scanner Sphere
Laser Scanner Sphere with magnetic base.
In stock
SKU
RSLB10M Magnetic Laser Scanner Sphere
RSLB10M Laser Scanner Sphere with special magnetic base:
-
Plastic scanning sphere featuring special matt textured lacquer for optimum reflection behaviour.
-
Shock-resistant plastic. Washable and dishwasher-safe surface
-
Fixed points for linking several viewpoints
-
Assignment of spatial reference information to a geodata set
-
Can be used from all sides
-
Suitable for indoor and outdoor use
-
Special magnetic base with 10 magnets for all metallic surfaces and other application
-
With recess for use in conjunction with RSFP-X90 fixed points
-
Also for use in conjunction with RSFP-X90-1 wich will then allow you to place the laser scanner spehere directly onto a tripod or trivet with a 5/8 thread
-
The 100 mm tilt axis height corresponds to common prisms so that the XYZ coordinates can also be determined easily and precisely using a total station
Technical data:
Diameter: Ø 145mm
Tilting axis height: 100 mm (RSLB10M)
Weight of scanner sphere (sphere only): 250 g
Tilting axis height: 100 mm (RSLB10M)
Weight of scanner sphere (sphere only): 250 g
Sphericity: 0.3 mm at 20 ºC
Accuracy radius: ± 0.15 mm at 20 ºC
